All-Terrain Knee
By
LegWorks
Quick Links
Product information
The All-Terrain Knee features patented AutoLock Technology promotes proper gait mechanics aiding in a more natural gait and energy efficient stride. The Variable Cadence Controller facilitates multiple walking speeds without the use of hydraulics or pneumatics.
- Simple twist-knob secondary manual lock
- Stance phase controller provides increased confidence on all terrains
- Supports transfemoral and knee disarticulation amputations
- Waterproof in fresh water
- Demo available upon request: Contact your Sales Representative to request a 30-day loaner to trial for your patient
Specifications
- Activity Level: K1, K2, K3, K4
- Knee Design Type: 4-Bar Linkage, Friction Swing Phase Control
- Axis: Polycentric
- Swing Phase: Friction, Variable Cadence Controller
- Stance Phase: Friction, AutoLock Technology
- Control Frame Material: Fiber-Reinforced Composites, Stainless Steel
- Product Weight (g): 1,040
- Maximum User Weight: 275lbs (125kg)
- Maximum Knee Flexion Angle: 150 Degrees
- Proximal Connection: Pyramid Adapter
- Distal Connection: 30mm Tube Clamp
- Trial Period: 30 day demo available upon request
- Warranty: 24 months from purchase date
| Activity Level: | K1 (Low), K2 (Moderate), K3 (High), K4 (Very High) |
|---|---|
| Amputation Level: | Knee Disarticulation, Transfemoral (TF/AK) |
| Key Features: | Waterproof |
| Material: | Thermal, Urethane |
| User: | Adult |
| Weight Limit: | 100 kg (220 lbs), 125 kg (275 lbs) |
| Axis Type: | Polycentric |
| Distal Connection: | Tube Clamp |
| Proximal Connection: | Male Pyramid Adapter |
| Stance Phase: | Friction |
| Swing Phase: | Friction |
