L1311A Weight Activated Brake Knee with Manual Lock

Product information


The L1311A Weight Activated Brake Knee with Manual Lock features a 2-in-1 function that can be used as part of the rehabilitation phase for patients. The ability to switch between a locked and weight activated brake knee joint adapts to patient’s progress.

  • Locking function for a high degree of safety for initial standing and gait exercises
  • Flexion and extension can be released depending on the patients progress
  • Individually selectable level of safety in definitive therapy
  • Rates of flexion and extension can be adapted to the user’s wishes

Specifications

  • Activity Level: K1, K2
  • Knee Design Type: Single Axis, Friction Swing and Stance Phase Control
  • Axis: Single Axis
  • Swing Phase: Friction
  • Stance Phase: Friction
  • Control Frame Material: Aluminum
  • Product Weight (g): 495
  • Maximum User Weight: 275lbs (125kg)
  • Maximum Knee Flexion Angle: 148 Degrees
  • Proximal Connection: Pyramid Adapter
  • Distal Connection: 30mm Tube Clamp
  • Trial Period: N/A
  • Warranty: 24 months from purchase date
Activity Level: K1 (Low), K2 (Moderate)
Amputation Level: Transfemoral (TF/AK)
Material: Stainless Steel
User: Adult
Weight Limit: 100 kg (220 lbs), 125 kg (275 lbs)
Axis Type: Single Axis
Distal Connection: Tube Clamp
Proximal Connection: Male Pyramid Adapter
Stance Phase: Friction
Swing Phase: Friction
